PE PP Pipe Hot Melt Fusion Welding Machines 90 To 250mm 2KW 220V

Product Categories

Sichuan Senpu Pipe Co., Ltd.

Contact Now

PE PP Pipe Hot Melt Fusion Welding Machines 90 To 250mm 2KW 220V

Name: PE PP Pipe Hot Melt Fusion Welding Machines 90 To 250mm 2KW 220V
Brand: SENPU
Price: 2.75 USD

Buy cheap PE PP Pipe Hot Melt Fusion Welding Machines 90 To 250mm 2KW 220V product

Place of Origin : Tianjin, Deyang

Supply Ability : ：20Set/per Day as requirement

Product Name : 250mm Hot Melt PE/PP Pipe Welding Machine

Brand : SENPU

Usage : ：welding

Voltage : ：110/220v

Dimensions : ：90-250

Frequency : ：0.58KW/220V

Power : ：2KW/220V

PackagingDetail : ：cartons

Brand Name : SENPU

Certification : WRAS, ISO, CE, IAPMO R&T

Model Number : DN16MM-DN1500MM

MOQ : 100PCS

Price : 2.75USD/METER

Packaging Details : carton box

Delivery Time : 5-10 working days

Payment Terms : TT, L/C

Contact Now

250mm Hot Melt PE/PP Pipe Welding Machine

Quick Details:

Model	SP250A
Max temperature	270℃
Temperature deviation	±5°C
Set temperature	220~270°C
Pressure range	0-6.3Mpa
Applicable	PE PPR PB PVDF
Welding range	90 - 250 mm
Input voltage	220V, 50Hz
Total power	5.05kw
Heating plate power	2.3kw
Planing tool power	2.0kw
Hydraulic unit power	0.75kw
Gross weight	145kg
Total Volume	0.6cbm

Product Description:

250mm Hot Melt PE/PP Pipe Welding Machine is the most popular welding method for HDPE piping system, and butt fusion welding machine is an industrial machine which is extensively demanded for welding purposes.

The SP160A Hydraulic butt fusion welding machine are made of four parts, including: planing tools, heating plate, basic frame & hydraulic unit (if hydraulic type), see the structure as below:

PE PP Pipe Hot Melt Fusion Welding Machines 90 To 250mm 2KW 220V Product Features:

250mm Hot Melt PE/PP Pipe Welding Machine Suitable for butt welding of plastic pipes and fittings made of HDPE, PPR and PVDF in a ditch in worksite or workshop. ※ Consists of basic frame, hydraulic unit, planing tool, heating plate, support for planing tool & heating plate, and optional parts. ※ Removable PTFE coated heating plate with high accurate temperature control system; ※ Electrical planing tool. ※ Be made of lightweight and high strength material; simple structure, small and delicate, user friendly. ※ Low starting pressure ensures reliable welding quality of small pipes. ※ Changeable welding position enables to weld various fittings more easily. ※ High accurate and shockproof pressure meter indicates clearer readings. ※ Separate two-channel timer records time in soaking and cooling phases.
